I underestimated how exciting the process of weaving a sampler can be. Some of the tie-up and treadling combinations gave me unexpected results which gave me ideas to try out a few of the patterns on a larger scale.
- Looking at the sampler below, starting at the left, is straight twill where your twill progresses in a single direction like a set of stairs. For this example, I threaded the shafts 1,2,3,4 (or the first thread on shaft 1, the second thread on shaft 2, the third thread on shaft 3 and the fourth thread on shaft 4, and so on).
- Point twill happens when a twill weave starts in one direction, for at least three threads (according to Helene Bress), and then reverses itself. For example, here I threaded 1,2,3,4,3,2, repeat.
- A broken twill is exactly what you might expect. Instead of progressing in a sequential numerical order, backward and/or forward, a break is made in the threading so that at least one harness is skipped in the order. For this example I threaded: 3,4,1,2,4 3 2 1, repeat.
- Extended point twill is created by combining straight twill and point twill. Here I've threaded: 1,2,3,4, 1,2,3,4, 3,2,1,2,3,4,3,2,3,4, repeat
- Bird’s Eye is a point twill or broken twill threading that traditionally creates a diamond pattern with a dot at its center. Here, I've threaded it: 4,3,2,3,4,1,2,3,4,3,2,1, repeat.
The fourth tie-up is a little bit different from the others. I got to thinking about my Wolf Pup, which is a direct tie-up loom. This means that each shaft (or harness) is attached to a single treadle. Table looms are similar in concept but use hand levers. To weave patterns that require multiple shafts to be raised at once, you press down multiple treadles or levers at one time. I got to thinking about how tying up a single shaft to a single treadle and using the direct tie-up technique of pressing down multiple treadles within the sequence might enable someone with a four-shaft loom with only four or six treadles or four levers to weave more complicated patterns. You will see the tie-up in this draft suggests that you need eight treadles. If you have them, great, but if you have fewer, simply tie-up 1-2-3-4, and when the draft indicates that you need to lift more than one shaft, use both of your feet, or hands in the case of a table loom, to accomplish this.
[Download a ZIP file of the drafts in WIF format, with their accompanying images,]
These samples showcase five common twill threadings across a single warp.
All of the samples (and drafts) are woven on the same threadings as listed above – straight, point, broken, extended point, and bird’s eye. The threading reads left to right and the treadling reads bottom to top. This will match the woven fabric in the photos.
Both sides of your cloth can be interesting and so different from each other. If you’re excited about something you find on the underside of your cloth, use the inverse of the tie-up to weave it on top. If you weave the first inch or so of cloth in plain weave as I did, you’ll see that a plain weave structure creates a thinner fabric with less draw-in, making a wider cloth.
You may find a new favorite pattern. Mine is found in draft three, the third treadling sequence of the point twill threading. It reminds me of a happy little flowerbed. The best thing about weaving a sampler is this sort of random discovery. Why not warp up your loom and give it a try?
-Melissa Ludden Hankens
-Melissa Ludden Hankens
You can find Melissa designing weaving projects for the Schacht newsletter and teaching at the Creative Warehouse in Needham, Massachusetts.
